Chinese SCOOTER - Stator Ø88mm (11 coils, 6 cables) 4T GY6-125/150cc
This is the DC fired, 11 Pole Stator Magneto Generator found on the 4 stroke, GY6-125cc and GY6-150cc. This fits engines with the 11 Pole Stator with engine numbers 152QMI 152QMJ 157QMI 157QMJ
- Stator: 11 coils
- Overall diamet...
Доставно тегло: 0,500 кг
Chinese SCOOTER - Stator Ø88mm (12 coils, 5 cables) 4T GY6-125/150cc
12 coil stator magneto commonly used on 4-stroke 125cc and 150cc GY6 scooter engines.
Overall diameter: 88mm
Center inner diameter: 29mm
Mounting Bolts Spacing: 41mm (center to center)
Stator: 12 coils
...
Доставно тегло: 0,600 кг
Chinese SCOOTER - Stator (6 coil, 5 cables) D-83mm:
6 coil magneto stator for 125cc-150cc GY6 gas scooters.
Overall diameter: 83mm
Center inner diameter: 29mm
Mounting Bolts Spacing: 41mm (center to center)
Stator: 6 coils
Plug: Male plug with 3 wires and 2 loose wires Total Wi...
Доставно тегло: 0,450 кг
Chinese SCOOTER - Stator Ø88mm (8 coils, 5 cables) 4T GY6-125/150cc
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
Overall diameter: 88mm
Center inner diameter: 29mm
Mounting Bolts Spacing: 41mm (center to cent...
Доставно тегло: 0,460 кг
Chinese SCOOTER - Stator Ø83mm (6 coils, 5 cables) 4T GY6-50/70/80cc (3+1+1 pin):
BAOTIAN:
BT49QT-10, BT49QT-11 Retro, BT49QT-12, BT49QT-12C1, BT49QT-D Hero, BT49QT-12G, BT49QT-18, BT49QT-20A2, BT49QT-2A Big Panther, BT49QT-2C Falcon, BT49QT-9 Ecobike, BT49QT-F1 Eagle, BT49QT-9F3 Eagle, BT49QT-9M, BT49QT-9N...
Доставно тегло: 0,430 кг
Chinese SCOOTER - Stator Ø88mm (8 coils, 3 cables) 4T GY6-50/70/80cc:
50cc INCA SPRINT 4T
Stator Width: 29 mm
Signaler thickness: 21 mm
Cable length: 550 mm
...
Доставно тегло: 0,400 кг
Chinese SCOOTER - Stator Ø88mm (8 coils, 4 cables) 4T GY6-50/70/80cc (2+1+1 pin) :
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
Overall diameter: 88mm
Center inner diameter: 29mm
Mounting Bolts Spacing: 41mm ...
Доставно тегло: 0,420 кг
Chinese SCOOTER - Stator Ø88mm (8 coils, 4 cables) 4T GY6-50/70/80cc 139E1006-2-2P
Order No.: ZD20012B
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
Overall diameter: 88mm
Center inner diameter: 29mm
Moun...
Доставно тегло: 0,400 кг
Chinese SCOOTER - Stator Ø88mm GY6-50/70/80 (8 coils, 5 cable) ONE HIGH-VOLTAGE COIL:
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
5 wires:
3 wires - Yellow, Green and White end in a 3 pin male plug
Red, Blu...
Доставно тегло: 0,420 кг
SCOOTER - Stator Ø80mm (8 coils, 5 cable) - (3+1+1 pin):
Use for:
ADLY Air Tech 50
ADLY Blizzard GTA 50
ADLY Cat 50
ADLY Jet 50
ADLY Nobel 50
ADLY Panther 50
...
Доставно тегло: 0,450 кг
|
