    | Резервни части за скутери и мотоциклети / Motorcycles & scooters products, spare parts | Универсални части / Universal parts | Запалване / Ignition
    140277
80,00 лв.
МАГНЕТ УНИВЕРСАЛЕН + ЕЛЕКТРОНЕН БЛОК (Рейсинг 50-160 ксм - 15000 об/мин) - ЗАПАЛВАНЕ С МАНИВЕЛА
Rapid Rotor / Racing Stator & CDI Kit
T-106 High performance racing magneto stator with CDI kit.
Universal for 50-160cc kick start horizontal engines
(Pls be noted that only kick start engines can use this magneto kit)
Applicable to:
For 49cc, 50cc 70cc, 90cc, 100cc, 110cc, 125cc, 140cc, 150cc and 160cc - ATVs, Quads, Dirt Bikes, Pit Bikes, Go Kart, Dune Buggies, Super Pocket Bikes, Mini-Choppers, Thumpstar and more.
CSM XR50 Junior Air
Honda XR50
Honda XR70
Honda Z50 Monkey
Kawasaki KLX110
Sikk MX 125
Sikk Trail 125
SSR 125
Thumpstar TSX-C 125
Yamaha TTR 110

Unleash the power!
This magneto kit offers better power, better starting and better performance of CDI. The engine can run in more stable condition.

FEATURES:
Up to 15,000 RPM's
Lighter weight,quicker response.
Super light rotor
Beautiful red anodized plate
Easy to install, comes with instruction

Sizes:
Overall Diameter: 115mm
Diameter of Central Hole: 17.80mm
Diameter of Fixing Hole(s): 6.50mm
Distance Between Fixing Holes (Centre of Eye to Centre of Eye): 101mm
Number of Fixing Holes: 2
Greatest Height: 53.20mm
White Stator Wire Length: 45cm
Black Stator Wire Length: 38cm
Distance between mounting holes (centre to centre): around 99.5mm

Kit includes:
New Stator Plate with crank seal and outer o-ring
Adjustable timing advance
Button Flywheel
15,000 RPM CDI Unit
Wiring diagram, instructio

Material Type: copper
External Testing Certification: CE
